Cartridge Specifications
-
- Cartridge Type
- Moving Coil, Low Output
-
- Output Level
- 0.5 mV at 5 cm/s
-
- Load Impedance
- 400 to 500 Ohms recommended
-
- Frequency Response
- 20Hz to 50kHz
-
- Channel Separation
- Greater than 30dB at 1Khz
-
- Compliance
- 6 x 10-6 cm/dyne
-
- Recommended Tracking Force
- 2.4 g
-
- Channel Difference
- Less than 0.3dB at 1kHz
-
- Total Mass
- 11 g
-
- Stylus
- Elliptical Diamond
-
- Cantilever Material
- Aluminum
Tonearm Specifications
-
- Bearing
- Sapphire and Ceramic
-
- Arm Tube
- Dural-Aluminum
-
- Counterweight
- Eccentric
-
- Adjustments
- Vertical Tracking Angle, Antiskate, Azimuth
Turntable Specifications
-
- Playback Speeds
- 33-1/3, 45 and 78 rpm
-
- Motor Type
- DC Brushless
-
- Speed Control
- Electronic w/ braking feature
-
- Platter
- Silicon Acrylic
-
- Platter Bearing
- Magnetic Suspended Ceramic
-
- Signal To Noise Ratio
- 41dB - 44dB
-
- Wow & Flutter
- 0.10% - 0.15%
Connectivity
-
- Stereo Outputs Unbalanced
- 1
Control
-
- Power Control Input
- 1
-
- Power Control Output
- 1
-
- Platter Light
- Yes
-
- Speed Control Fine Adjustment
- Yes
General Specifications
-
- Dust Cover Included
- No
Weights & Dimensions
-
- Unit Dimensions (W x H x D)
- 17-1/2" (44.45cm) x 8-13/16" (22.38cm) x 21" (53.34cm)
Note: Tone Arm Height will vary depending on the type of Cartridge installed.
-
- Unit Weight
- 42 lbs (19 kg)
-
- Shipping Weight
- 63 lbs (28.6 kg)
