690 AC
2-way coaxial kit
This 16.4 x 23.5 cm coaxial kit is designed to reproduce deep bass throughout the vehicle. It will easily find its place in the doors or on the rear parcel shelf of your car (depending on the original location). As with other Access products, you can quickly connect your kit to a car radio or amplifier, thanks to the integrated crossover.
PERFORMANCE
Highly resistant DFS® diaphragm, reliable butyl suspension, robust, anti-resonant ABS bowl, optimized 30 mm coil, high-efficiency 90 mm motor, integrated crossover for quick and easy installation: the 690 AC kit is at the service of performance.
SOUND SPATIALIZATION
Positioned on angled, adjustable mounts, the aluminum inverted dome tweeters provide excellent spatialization of sound, optimizing the soundstage within the passenger compartment. High frequencies are revealed with finesse and precision.
Specifications
- Product type : 2-way coaxial kit
- Membrane :
DFS - Tweeter :
164x235 mm - Filter : Integrated
- Frequency response (+/- 3dB) :
50Hz - 20kHz - Maximum power : 150 watts
- Maximum SPL (peak@1m) :
88.09 DECIBEL - Motor : Ferrite
- Nominal Impedance : 4 Ω
- Nominal power : 75 W RMS
- Sensitivity : 91.3 dB
- Surround material : Butyl
- Weight : 1050 g / 2.1 lb
- Depth behind surface (Mounting depth) : 81.7 mm / 3.21 in
