ACX 570
2-way elliptical coaxial kit
FOCAL KNOW-HOW
Adjustable tweeter with mylar inverted dome, elliptical polypropylene diaphragm, butyl suspension: ACX 570 benefits from Focal expertise for precise, dynamic and spatialized sound.
COMPLEMENTARITY
ACX 570 can be paired with electronics or directly connected to the vehicle's original amplifier for in-car listening pleasure. Its high power handling and high sensitivity guarantee an excellent level of performance in its class.
DESIGN
The kit is supplied with ABS and Mesh grilles, for sleek styling and versatile installation, fully integrated or surface-mounted. Rigid steel loudspeaker bowls guarantee long-lasting durability.
Specifications
- Product type : Elliptical 2-way coaxial kit
- Membrane :
Polypropylène - Tweeter :
130x180 mm - Filter : Integrated
- Frequency response (+/- 3dB) :
60Hz - 21kHz - Maximum power : 120 watts
- Motor : Ferrite
- Nominal Impedance : 4 Ω
- Nominal power : 60 W RMS
- Sensitivity : 91.6 dB
- Surround material : Butyl
- Weight : 1000 g / 2.2 lb
- Cut-Out diameter : 181 mm / 7.13 in
- Depth behind surface (Mounting depth) : 59.5 mm / 2.32 in
