Focal FPX 1.1000 Monoblock Amplifier – SoundHub

Focal FPX 1.1000 Monoblock Amplifier

  • Sale
  • Regular price $899.00
Tax included.


FPX 1.1000

Mono amplifier 420w RMS

The FPX 1.1000 is a very compact mono amplifier offering 420 watts RMS of power into 4 ohms. It combines high power, high efficiency, optimized heat dissipation, multiple features and compactness for remarkable performance and listening pleasure in the car.

POWERFUL BASS

Compact and easy to integrate into the vehicle, this Class D amplifier is designed to drive all types of subwoofers. Stable at 4, 2 and 1 ohms, it delivers 420, 700 and 1000 watts RMS power respectively. It features all the settings required for a highly efficient amplifier.


HEAT DISSIPATION

For a powerful, musical amplifier, heat dissipation is essential. That's why FPX amplifiers are built on thick aluminum frames with optimal cooling capacities.


MULTIPLE INSTALLATIONS

The FPX 1.1000 has a remote control for bass level control from the front of the vehicle, and a pair of line outputs for distributing the sound signal to a second amplifier. This feature is ideal for creating a bass channel with two subwoofers and two amplifiers.

AUDIO SPECIFICATIONS
CEA power (4 ohms) 1x420 Watts rMS
Max. power (2 ohms) 1x700 Watts rMS
Max. power (1 ohm) 1x1000 Watts rMS
Bandwidth (-3dB) 15Hz – 250Hz
THD 0,08 %
SNR (1W/A) > 76dBA

GENERAL FEATURES
Subsonic filter 10Hz-50Hz
(24dB/oct)
High-pass/low-pass filter Low-pass
50Hz-250Hz
(24dB/oct)
Bass boost 0 to 12dB linear
Phase 0 to 180° linear
Standby current (A) 1.75 A
Remote control ✓
Protections Short circuit/low impedance/
reverse polarity/dC/voltage
drop/overheat protection
Dimensions
(LxWxH)
(297x132x53mm)
Weight (kg) 5.62lbs (2.55kg)
Operating voltage range 8.3 to 16V
