Marantz AV30 (Dolby Atmos)
Marantz AV30 (Dolby Atmos)
Regular price
$7,999.00 NZD
Regular price
Sale price
$7,999.00 NZD
Taxes included.
AV 30 delivers exceptional performance and capability for large media rooms and dedicated home theater systems. This 11.4-channel balanced AV preamplifier features Marantz HDAM discrete circuitry and boasts seven HDMI inputs, each of which is 8K Ultra HD compatible. Powered by HEOS™ for high-resolution music streaming, AV 30 includes room correction with Audyssey MultEQ XT32 and optional Dirac Live. It delivers Dolby Atmos, DTS:X Pro, AURO-3D, and features multiple inputs and balanced pre-amp outputs for all channels, including four independent subwoofers.
- Crafted in Shirakawa, Japan
- 11.4 Channels
- 7 HDMI Inputs plus eARC
- 8K and Dolby Atmos
- 3D Audio
- Powered by HEOS™
Elevated Listening Begins Here
AV 30 is engineered to bring exceptional cinema sound into your home. Advanced Marantz technology and expert craftsmanship ensure your entertainment is always delivered with powerful precision—from an elegant, timeless design.
Enjoy every movie moment with immersive realism and lifelike detail. AV 30 delivers an outstanding theater experience—in your home.
The 11.4-channel onboard processing supports a wide range of speaker configurations. Perfect for all forms of immersive audio suitable for even large home theater systems.
AV 30 comes packed with support for the latest high-resolution movie formats, plus 8K video compatibility, room optimization, and Powered by HEOS™ technology to simplify and elevate your listening.
A modern expression of timeless design principles, AV 30 features the iconic Marantz porthole, premium materials, and subtle sidelights that illuminate the front panel.
Multichannel Surround
-
DTS DTS-HD Master Audio, DTS:X,
DTS Virtual:X, DTS Neural:X -
Dolby Dolby TrueHD, Dolby Atmos,
Dolby Atmos Height Virtualization,
Dolby Surround - IMAX IMAX Enhanced
- Auro 3D / 360 Reality Audio / MPEG H Yes / Yes / Yes
- Multichannel Stereo Yes
- Max Number of Processing (Pre-amp) Channels 11.4
Sound Enhancements
- Copper-Plated Chassis / Toroidial Power Transformer Yes / Yes
- Current Feedback Topology / Hyper Dynamic Amplifier Modules (HDAM) Yes / Yes (HDAM-SA2)
- Pure Direct / Gold-Plated RCA Terminals Yes / Yes
- Clock Jitter Reducer Yes
- Dirac Live upgradability Yes
- Compressed Audio Enhancer: MDAX2 Yes
- Audyssey Dynamic EQ / Dynamic Volume / Audyssey LFC Yes / Yes / Yes
- Audyssey MultEQ XT32
Network
- Wi-Fi / Bluetooth / Ethernet Yes / Yes / Yes
- HEOS Multi-Room and Streaming Yes
- Bluetooth Retransmit for Bluetooth Headphones Yes
- Apple HomePod Yes
- Lossy formats MP3, WMA, AAC
-
Lossless formats FLAC, FLAC HD 192/24,
ALAC, ALAC 192/24,
WAV, WAV 192/24 - DSD Audio Streaming Yes (up to DSD5.6)
- Gapless Playback FLAC, ALAC, WAV, DSD
- TuneIn / AirPlay 2 / Spotify Yes / Yes / Yes
- Roon-Ready Yes
-
Other Streaming Services* Amazon Music / TIDAL /
Deezer / Napster / SoundCloud - Compatible with Remote App for Smartphones Marantz AVR Remote
- Compatible with Remote App for Tablets Android / iOS / Amazon Kindle
HDMI
- Total HDMI Inputs 7
- HDCP 2.3 Support Yes
- HDMI Outputs: Main / Zone 2 / 1
- HDMI Scaling 1080P/4K to 8K
- GUI Overlay on HDMI Yes
- HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB Yes / Yes
- 8K/60Hz AB / 4K/120Hz AB Pass-Through In/Out 7 / 2 (up to 40 Gbps)
- HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR Yes / Yes / Yes / Yes / Yes
- Enhanced ARC Yes
- ALLM (Auto Low Latency Mode) Pass-Through for Gaming Yes
- Variable Refresh Rate / Quick Frame Transport Yes / Yes
- HDMI Pass-Though in Standby Mode Yes
- DSD Audio Capability Yes
- Auto LipSync Yes
Inputs Outputs
- Composite In / Out 2 / 0
- Component In / Out 1 / 0
- HDMI In / Out 7 / 3
- Multi-Room Video Out: Video / HDMI No / Yes
- Analogue In 6 (1x XLR)
- Phono (MM) In Yes
- Digital In: Optical / Coaxial 2 / 2
- Multi-Room Out: analog / digital 2 / 0
- Multichannel Pre-Amp Out Yes (11.4 RCA, 11.4 XLR)
- Subwoofer Out 4 (independent)
- Speaker A / B Assignable Pre-Out
- Bi-Amp Drive Assignable Pre-Out
- Front USB Input / USB Audio Yes / Yes
- USB Power Supply (Rear) Yes
- AM/FM Tuner Yes
Multi-Room CI
- HEOS Multi-Room Integrated Yes
- HEOS Link Compatibility: IR/ IP Yes / Yes
- Multi-Room Zones 3
- Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analogue Yes (2 ch) / Yes (2 ch) / Yes / Yes
- Zone Audio Output: Speaker / Pre-Out No / Yes
- Zone HDMI Output from HDMI Source Yes
- IP Control / RS232 Control / Web Control / App Control Yes / Yes / Yes / Yes
- IR Flasher In / Marantz Remote Bus Yes / Yes
- DC Trigger Output 3
- HDMI Diagnostics Yes
Others
-
Auto Speaker Setup by Microphone Audyssey MultEQ XT32
Dirac Live (Upgrade) - Front Display 2-Line FLD, Port Hole OLED
- Graphic User Interface Modern HD GUI
- GUI Languages 9
- Setup Assistant / Smart Select Yes / Yes
- Firmware Update by Network / USB Yes / Yes
- Variable Cross Over / Optimized Bass Redirection / Bass Sync Yes / Yes / Yes
- Auto Power Off / Sleep Timer Yes / Yes
General
- Metal Front Panel Yes
- System Remote Control RC053SR
- Backlit Yes
- Power Consumption 80 W
- Standby Consumption 0.2 W
- CEC Standby Consumption in W 0.5 W
- Network Standby Consumption 2.0 W
-
Maximum Dimensions
Antenna: Horizontal:(W x D x H)
Antenna: Vertical :(W x D x H)
w/o Antenna: (W x D x H)
17.4 × 16.3 × 7.5 in.
17.4 × 16.3 × 10.0 in.
17.4 × 15.6 × 7.5 in. - Weight 24.5 lbs.
-
What's in the box Main unit, remote control,
batteries,
wire labels, quick start guide,
Audyssey microphone, card
board microphone stand,
2 External Detachable Antenna,
AC cord - UPC Code 747192143817
- Limited Warranty (United States and Canada) 5-year
