NAD C338 – SoundHub

Stereo Amplifier NAD C338
Stereo Amplifier NAD C338
Stereo Amplifier NAD C338
Stereo Amplifier NAD C338

NAD C338

  • Sale
  • $1,299.00
Tax included.

NAD's Most Versatile Amplifier Ever with Chromecast built-in and Hybrid Digital Technology

Introducing the NAD C338

Getting the Basics Right

Built with NAD’s renowned music-first approach to audio architecture and amp design, the C 338 is equipped with the most advanced components commonly found in NAD’s class-leading line of amplifiers. Always starting with the details you can hear and advancing from there, NAD develops low-noise circuitry with the precision and stability to deliver incredible, near-zero distortion sound for the most difficult speakers.

HybridDigital™ Amp Technology

The search for a high-performance Class D solution led NAD to HybridDigital™, an innovative amplifier technology that uses a variable modulation frequency to bring out the life-like qualities of music, while reducing distortion under every operating condition. This highly optimized design gives phenomenal performance to the C 338 amplifier, both measured and subjective.

Efficient Class D Power

NAD has worked tirelessly to create the best performing Class D amplifiers that are energy efficient and produce beautiful sound—not heat—regardless of basic design principles. Using advanced measurements and data, NAD developed the C 338’s highly efficient power supply with a customised Hypex® UCD output stage to pump out 50 watts continuously and over 200 watts instantaneously to meet the demands of the most dynamic music. This new design is very linear over a wide bandwidth and provides consistent, noise-free performance for the amplifying stages with near perfect regulation of voltage.

Always Ready for Streaming

The C 338 has Chromecast built-in so you can cast music, tunes, podcasts, and playlists from your favourite apps on your phone, tablet or laptop to your stereo system. Spotify Connect® lets you discover millions of songs and stream them directly to your C 338 using the Spotify® app for a rich, wireless music experience. With the added flexibility of Bluetooth®, your music streaming possibilities are truly limitless with the C 338.

Built-in Phono Stage for Vinyl Listening

Using a MM phono stage and an innovative low-noise circuit path, the C 338 can reproduce the warmth of LPs with accurate RIAA equalization and control the infrasonic noise that is in all recordings, without ever affecting the bass response.

Flexible Connectivity

With a wide array of connections, including a separate headphone amplifier that can drive high-impedance studio monitor headphones, the C 338 is ready for any type of listening. Line inputs can accommodate all kinds of analogue source components, offering ideal input impedance with linear ultra-low noise buffer amplifiers to preserve the musicality of recordings. Also connect a subwoofer with low impedance line outputs and extend the versatility of this budget-friendly, do-it-all amplifier.

Key Features

  • 50W x 2 Continuous Power into 8 or 4 Ohms
  • 90W / 150W / 200W IHF Dynamic Power into 8 / 4 / 2 Ohms
  • First hi-fi amplifier to feature Chromecast built-in
  • Integrated Bluetooth® for added music streaming flexibility
  • Built-in Phono Preamp for Turntables
  • Stereo Line, Optical Digital and Coax Digital inputs
  • NAD Remote App support for tablet and smartphone
  • Dedicated Headphone Amplifier
  • Subwoofer Output

Preamplifier

Line In, Subwoofer Out

  • THD (20Hz-20kHz)
  • <0.005% at 2V out
  • Signal/Noise Ratio
  • >106dB (IHF; A-weighted, 500mV out, unity gain)
  • Input Impedance (R and C)
  • 56 kilohm + 100pF
  • Maximum Input Signal
  • >4.5Vrms (ref. 0.1% THD)
  • Output Impedance
  • Source Z + 200 Ohm
  • Input Sensitivity
  • 50mV (100Hz ref. 500mV out, Volume maximum
  • Maximum voltage output – IHF load
  • >4.5V (ref. 0.1% THD)

Line In, Headphone Out

  • THD (20Hz-20kHz)
  • <0.005% at 1V out
  • Signal/Noise Ratio
  • >105dB (IHF; A-weighted, 32 Ohm loads, ref. 2V out, unity gain)
  • Frequency Response
  • ±0.3dB (20Hz-20kHz)
  • Channel Separation
  • >56dB at 1kHz
  • Output Impedance
  • 0.5 Ohm

General Specifications

Line In, Speaker Out

  • Continuous Output Power into 4 Ohms and 8 Ohms (Stereo)
  • >50W (at rated THD, 20-20kHz, both channels driven)
  • IHF Dynamic Power
  • 8 Ohm 80W
    4 Ohm 150W
    2 Ohm 210W
  • THD (20Hz-20kHz)
  • <0.03% (250mW to 50W, 8 Ohm and 4 Ohm
  • Signal/Noise Ratio
  • >98dB (A-weighted, 500mV input ref. 1W out in 8 Ohm)
  • Clipping power
  • >60W (at 1kHz 0.1% THD)
  • Peak output current
  • >18A (in 1 Ohm, 1 ms)
  • Damping Factor
  • >300 (ref. 8 Ohm, 20Hz to 6.5kHz)
  • Frequency Response
  • ±0.3 dB (20Hz-20kHz)
  • Channel Separation
  • 1kHz >75dB
    10kHz >65dB
  • Input Sensitivity (For 50W in 8 Ohm)
  • Line In: 380mV, Digital In: 18% FS
  • Sample Rate
  • Up to 24 bit/192kHz

Phono In, Speaker Out

  • THD (20Hz-20kHz) (Stereo)
  • <0.3% at 50W out
  • Signal/Noise Ratio
  • >82dB (200 Ohm source, A-weighted, ref. 500mV out)
    >76dB (MM cartridge source, IHF A-weighted, ref. 500mV out)
  • Input Sensitivity
  • 4.1mV (ref. 50W 1kHz 4 Ohm out, Volume maximum)
  • Frequency Response
  • ±0.3dB (20Hz-20kHz)
  • Input Impedance
  • 47 kilohm + 100pF
  • Maximum Input Signal
  • >80mVrms (ref. 0.1% THD)

Power Consumption

  • at ECO Standby mode
  • 0.4 Watts*
  • at Control Standby mode
  • 1.8 Watts**
  • OFF mode (Power switched OFF)
  • 0 Watts



* – After 20 minutes of no user interface interaction and no active source input
** – With established wireless Bluetooth connectivity and 20 minutes of no user interface interaction and no active source input

NOTE: Bluetooth connectivity can be enabled or disabled via press and hold of PLAY button of AMP 3 remote control

Weight & Dimensions

  • Gross Dimensions (W x H x D)*
  • 435 x 70 x 285mm (17 1/8 x 2 13/16 x 11 1/4)”
  • Net Weight
  • 4.85kg (10.7lb)
  • Shipping Weight
  • 5.85kg (12.9lb)

*Gross dimensions include feet, extended buttons and rear panel terminals

Accessories

nad_website_accessoriesicons_uspowercord nad_website_accessoriesicons_srhtrremote nad_website_accessoriesicons_aabatteries
