Price on application
The Toko digital audio player is equally at home with a conventional CD in its slot loaded transport or when connected to an Ethernet network, you can connect the Toko to your other DLNA compatible components, for example a P.C.
FEATURES
RC5 INPUT
The RC5 input allows for connection to wired remote interfaces so it can be used as part of an automated system, or if it is required to be located out of the line of sight from a standard remote.
BURR BROWN DAC
The DAC and interface receiver are high performance Burr Brown components with a proven record of quality digital sound reproduction.
The chosen DAC allows playback of popular file types up to 24bit/192ks/s.
ALUMINIUM CONSTRUCTION
The aluminium chassis, lid and panels provide a non-magnetic housing to eliminate unwanted magnetic fields that can interfere with the sensitive audio signals.
WBT AND NEUTRIK CONNECTORS
High quality WBT RCA and Neutrik XLR output connectors ensure a high performance, low distortion interface between your cables and the player.
Compact Disc Slot
Primarily designed as a network player, a compact disc transport is also on board to allow playback of standard CD’s
File Formats
Playback is supported for FLAC, LPCM, AIFF ALAC and MP3 including Gapless.
Network Input
The RJ45 connector allows network connection for playback of digital music over a home network. Network input was chosen as the most suitable way to transfer digital audio due to ease of setup, ability for wireless communication and advantages over S/PDIF and USB.
SPECIFICATIONS
| SUPPORTED AUDIO FILE SERVER | DLNA Digital Media Servers |
| SUPPORTED PLAYBACK CONTROL | DLNA Digital Media Controllers, DLNA Mobile Digital Media Controllers, UPnP smartphone applications, iPad/iPod applications |
| DAC CAPABILITY | 24 bit, 192ks/s |
| AUDIO CODEC SUPPORT | FLAC (up to 24/192), LPCM (up to 24/192), AIFF, MP4 |
| CONNECTIVITY | 10/100 Ethernet |
| ANALOGUE OUTPUT | 1 x RCA stereo pair 1 x XLR stereo pair |
| Frequency Response | 20Hz to 20kHz ±0.2dB |
| SIGNAL to Noise Ratio | -100dB at rated input level, A Weighted |
| DISTORTION | <0.01% THD at rated input level |
| INPUT | 1 x RJ45 connector |
| MAXIUM OUTPUT LEVEL | 2V RMS into 10k or higher |
| OUTPUT SOURCE IMPEDENCE | Typically 100R |
| POWER/CURRENT CONSUMPTION | 60W 0.22A (53W) Idle |
| Height | 105mm (4") |
| Width | 450mm (17 3/4") |
| Depth | 400mm (15 3/4") |
| Weight | 10kg (22lbs) |
