The K3 CD Di Player is a fully featured smooth and detailed performer that offers a peerless high-end experience.
The K3 CD Di Player is the latest of our many award-winning CD players. It offers analogue and digital outputs as well digital inputs.
Speciality selected components including an advanced precision crystal master clock and a high quality internal 24 bit/192 kHz DAC results is a smooth open sound full of detail. Vocals are clean and lyrical, rhythms are solid and tight. The K3 CD Di delivers an involving musical performance ensuring maximum enjoyment from every disc played.
Key Features
- Superior build quality
- High quality PCM1798 24 bit / 192 kHz DAC
- 75 Ohm RCA gold plated RCA digital input
- Optical Toslink digital input
- High precision, custom made Master Clock Crystal
- 110 Ohm balanced gold plated XLR digital output
- Gold plated RCA analogue outputs
- Front loading CD drawer
- Display showing track number, time elapsed, time remaining
- Shuffle play
Operating System
CD Digital Audio System (CD, CD-R, CD-RW)
Inputs
RCA (75 ohms), Optical
Outputs
RCA (75 ohms), XLR (110 ohms), Optical
Output Voltage
2.2 V rms
Frequency Response
20 Hz – 20 kHz (± 0.2 dB)
Harmonic Distortion
< 0.002 % @ 0 dB, 1 kHz, < 0.006 % @ -30 dB,1 kHz,
< 0.002 % @ 0 dB, 20 Hz, < 0.008 % @ 0 dB, 20 kHz
Signal to Noise Ratio
< 96 dB (L & R)
Wow & Flutter
Quartz Precision
Channel Separation
100 dB @ 1kHz / 80 dB @ 20 kHz
D/A Conversion
PCM1730E advance segment
Resolution/Sampling
24 bits / 192 kHz
Oscillation
3rd overtone oscillation
Crystal
Super precision, custom made
Jitter
< 150 psec
Idle Pattern
< -107 dB L&R
Stop-Band Rejection
< -98 dB
Power Supply
Toroidal transformer, 7 fully regulated power rails
Dimensions (W x H x D)
432 x 105 x 380 mm
Weight
8 kg
